A Study on Strength Characteristics of Confined Concrete Columns using Textile Reinforced Concrete

Based on the experimental investigation, the following conclusions are drawn: ●          The addition of TRC to RCC columns led to substantial increases in compressive strength ranging from 52.21% to 71.96% across curing ages of 7, 14, and 28 days, for both 150×150×500 mm and 200×200×500 mm column sizes. ●          The significant strength improvements achieved suggest that TRC confinement could enable the use of smaller column dimensions while maintaining required load-bearing capacity, leading to more efficient structural designs and potentially reduced material usage. ●          Consistent strength enhancements across two different column sizes demonstrate the versatility of the TRC reinforcement approach, indicating that its benefits can be leveraged across a wide range of structural applications. ●          The smaller TRC-C1 column (150×150×500 mm) outperformed the larger RCC-C2 column (200×200×500 mm) in compressive load capacity, confirming the potential benefits of TRC in terms of load-bearing capacity and overall strength. ●          TRC utilisation offers enhanced design flexibility; the observed dimensional efficiency with TRC suggests that this material can achieve desired structural properties while potentially reducing the overall weight of the structure. ●          The substantial increases in compressive load achieved with TRC reinforcement indicate that this technique can contribute to enhanced structural performance, including improved load-bearing capacity, ductility, and overall durability of RC columns.

[1] Polienko, W. and Holschemacher, K. (2023). “Investigation into the Effectiveness of a Column Confinement with Textile Reinforced Concrete (TRC).” Conference Paper, July 2023. [2] Zhang, Q. et al. (2022). “Confinement behaviour and stress-strain response of concrete columns strengthened with carbon textile reinforced concrete (CTRC) under uniaxial load.” Construction and Building Materials. [3] Ngo, D.Q., Nguyen, C., Mai, L. and Vu, V. (2020). “Experimental and Numerical Evaluation of Concentrically Loaded RC Columns Strengthening by Textile Reinforced Concrete Jacketing.” Civil Engineering Journal, Vol. 6, No. 8. [4] Faleschini, F., Zanini, M., Hofer, L. and Pellegrino, C. (2020). “Experimental behaviour of reinforced concrete columns confined with carbon-FRCM composites.” Construction and Building Materials, 243, 118296. [5] John, S.K. et al. (2020). “Studies on TRM confined concrete columns.” Journal of Materials in Civil Engineering, ASCE. [6] Eid, R. et al. (2019). “High-Strength Concrete Circular Columns with TRC-TSR Dual Internal Confinement.” Buildings, Vol. 9, Issue 218. [7] Yang, J. et al. (2018). “Eccentric behaviour of high-strength concrete columns confined with carbon fibre-reinforced polymer (CFRP).” National Natural Science Foundation of China. [8] Liu, S., Zhu, D., Yao, Y. and Shi, C. (2018). “Effects of Strain Rate and Temperature on the Flexural Behaviour of Basalt and Glass Textile-Reinforced Concrete.” Journal of Materials in Civil Engineering, ASCE. [9] Gopinath, S. et al. (2016). “Investigations on textile-reinforced concrete as cover for RC beams.” Magazine of Concrete Research. [10] Portal, N., Lundgren, K., Wallbaum, H. and Malaga, K. (2014). “Sustainable Potential of Textile-Reinforced Concrete.” Journal of Materials in Civil Engineering, ASCE.
