Automation and IoT Based Vertical Car Parking System

This work successfully designed, fabricated and tested a working prototype of an Automation and IoT Based Vertical Car Parking System that automates parking and retrieval across two floors and six slots through the integration of stepper-driven vertical lift, DC-motor rotational platforms, RFID authentication, ultrasonic occupancy sensing, limit-switch safety and Blynk-based IoT monitoring. All twelve functional test cases passed, slot detection achieved 100% accuracy, and average parking/retrieval times of 18–26 seconds were recorded — demonstrating that a low-cost, readily reproducible prototype can validate the working principle of a vertical automated parking structure that is, in principle, scalable to full-size deployment. Future enhancements identified for this work include scaling to a full-size tower using industrial-grade servo motors and PLC control; integrating an automated fee-payment gateway (UPI / RFID wallet); adding a mobile app for remote slot reservation; incorporating CCTV with license-plate recognition for security; powering the control electronics via solar panels; extending the structure to 4–6 floors with 12–18 slots; adding voice announcements; and logging parking events to a cloud database such as Firebase or ThingSpeak for analytics.

[1]   S. K. Singh, A. Kumar, and P. R. Gupta, “Design and Implementation of Automated Multi-Level Car Parking System Using PLC and RFID,” International Journal of Engineering Research and Technology, vol. 9, no. 3, pp. 112–118, March 2020. [2]   R. Patil and M. Shinde, “IoT Based Smart Parking System Using NodeMCU and Ultrasonic Sensors,” International Journal of Innovative Research in Computer Science & Technology, vol. 9, no. 2, pp. 45–51, April 2021. [3]   A. Joshi, B. Mehta, and C. Shah, “Design of Automatic Car Parking System Using Arduino and Servo Motors,” Proceedings of the International Conference on Electronics and Communication Systems, pp. 234–239, 2019. [4]   T. Verma and S. Agarwal, “Vertical Carousel Automated Parking Using Stepper Motors and Lead Screws,” Journal of Mechanical and Electrical Engineering, vol. 14, no. 1, pp. 78–85, January 2022. [5]   M. Kulkarni and P. Deshmukh, “RFID Based Vehicle Access and Parking Management System,” International Journal of Advanced Research in Electrical, Electronics and Instrumentation Engineering, vol. 10, no. 6, pp. 3321–3328, June 2021. [6]   N. Rao and L. Krishnamurthy, “Real-Time Parking Monitoring using Blynk IoT Platform with ESP32,” International Journal of Electronics and Electrical Engineering, vol. 10, no. 4, pp. 189–196, August 2022. [7]   Espressif Systems, ESP32 Technical Reference Manual, Version 5.0, Espressif Systems, Shanghai, 2023. [8]   Texas Instruments, DRV8825 Stepper Motor Controller IC Datasheet, SLVSA73D, Texas Instruments Inc., Dallas, TX, 2014. [9]   NXP Semiconductors, MFRC522 Standard Performance MIFARE and NTAG Frontend Datasheet, Rev. 3.9, NXP B.V., Eindhoven, 2016. [10]                        STMicroelectronics, L298N Dual Full-Bridge Driver Datasheet, SGS-Thomson Microelectronics, Geneva, 2000. [11]                        Texas Instruments, LM2596 SIMPLE SWITCHER Power Converter 150 kHz 3A Step-Down Voltage Regulator Datasheet, SNVS124J, Texas Instruments Inc., Dallas, TX, 2013. [12]                        Blynk Inc., Blynk Documentation for IoT Platform, Version 2.0, 2023.
