Automation and Real-Time Data Integration for Magnetic Field Testing in Magmeter Manufacturing

This paper described the design and testing of a semi-automated magnetic field data logging system built around the BGM101 Gaussmeter and LabVIEW. The core contribution is the integration of a proprietary DLL-based instrument interface with a relational database backend — a combination not widely reported in existing literature for this class of instrument.   Experimental runs confirmed one-second logging intervals, zero communication failures during testing, and DC mean values stable in the 0.000919 T to 0.000922 T range under consistent field conditions. The MySQL database accumulated records with accurate timestamps throughout, validating the end-to-end data path from instrument probe to stored record.   Future work will extend the system to include threshold-based pass/fail logic directly in the LabVIEW VI, automated report generation from the MySQL data, and full deployment of the React operator dashboard on the production floor at Krohne Marshall Pvt. Ltd.

[1] J. Travis and J. Kring, LabVIEW for Everyone, 3rd ed. Pearson Education, 2007.   [2] National Instruments, “LabVIEW User Manual,” NI Publications, 2024.   [3] P. Horowitz and W. Hill, The Art of Electronics, 3rd ed. Cambridge University Press, 2015.   [4] Oracle Corporation, “MySQL Reference Manual,” Oracle Documentation, 2025.   [5] BELL Technologies, “BGM101 Gaussmeter User Manual,” Product Documentation, 2024.   [6] X. Zhang, "The real-time monitor system based on LabVIEW," 2012 International Conference on Computer Science and Electronics Engineering (ICCSEE), Hangzhou, China, 2012, pp. 570-573, doi: 10.1109/ICCSEE.2012.106.   [7] S. Q. Liu, Z. S. Ji, Y. Wang and Z. C. Zhang, "Real time state monitoring and fault diagnosis system for motor based on LabVIEW," 2019 IEEE 8th Joint International Information Technology and Artificial Intelligence Conference (ITAIC), Chongqing, China, 2019, doi: 10.1109/ITAIC.2019.8969523.   [8] A. Konovalov et al., "Industry 4.0 LabVIEW Based Industrial Condition Monitoring System for Industrial IoT System," 2020 IEEE International Conference on Industry 4.0, Artificial Intelligence, and Communications Technology (IAICT), Bali, Indonesia, 2020, doi: 10.1109/IAICT50021.2020.9073068.   [9] J. Pelegrí-Sebastiá, J. Sogorb and T. Sogorb, "DC Digital Gaussmeter Based on Linear Hall-Effect Sensor IC," 2019 IEEE SENSORS, Montreal, QC, Canada, 2019, doi: 10.1109/SENSORS43011.2019.8905856.   [10] R. Hejtmanek and J. Roubal, "Reducing the Noise Level in a Gaussmeter with a Hall Probe for Reliable Magnetic Impedance Tomography," 2020 IEEE International Instrumentation and Measurement Technology Conference (I2MTC), Dubrovnik, Croatia, 2020, doi: 10.1109/I2MTC43012.2020.9017573.
