Battery-Based HESS with Ultracapacitor Assistance for Electric Vehicles Considering Ageing Batteries

The suggested Hybrid Energy Storage System (HESS) greatly extends the life of electric car batteries by enabling the ultracapacitor to manage abrupt surges in power demand caused by acceleration and changes in dynamic load. The Energy Management Strategy, based on Model Predictive Control (MPC), is able to efficiently optimize the distribution of energy between the ultracapacitor and lithium-ion battery in various driving conditions.  We analyze the aging of batteries in this study under both constant and variable C-rate operation, both in battery-only and battery-with-ultracapacitor operation. Since the current flow through the battery changes continuously depending on the load conditions, it is seen that the results indicate that the value of the C-rate is misleadingly assumed constant during the entire driving cycle, which is why the calculation of battery degradation is incorrect. To get accurate capacity fade estimate, the actual battery current profile is continuously recorded during driving cycle to compute C-rate values in real-time. The results demonstrate that the HESS arrangement slows down battery ageing. This is because the ultracapacitor absorbs the transients of electrical current and peak power from the battery, thereby lowering the electrical and thermal stress on the battery. Furthermore, the current changing C-rate provides more accurate and realistic results compared to the usual C-rate assumption for battery aging. Intelligent power sharing with MPC improves electric vehicle energy storage systems' long-term performance and reliability, decreases battery deterioration, boosts voltage stability, and improves energy consumption efficiency, according to the research.

[1] W.Vermeer,G. R. ChandraMouli, and P. Bauer, “A comprehensive review on the characteristics and modeling of lithium-ion battery aging,” IEEE Trans. Transp. Electrific., vol. 8, no. 2, pp. 2205–2232, Jun. 2022.   [2] J. Cao and A. Emadi, “A new battery/ultracapacitor hybrid energy storage system for electric, hybrid, and plug-in hybrid electric vehicles,” IEEE Trans. Power Electron., vol. 27, no. 1, pp. 122–132, Jan. 2012.   [3] J. Wang, B. Wang, L. Zhang, J. Wang, N. I. Shchurov, and B. V. Malozyomov, “Review of bidirectional DC–DC converter topologies for hybrid energy storage system of new energy vehicles,” Green Energy Intell. Transp., vol. 1, no. 2, 2022, Art. no. 100010, doi: 10.1016/j.geits.2022.100010.   [4] Y. Wu et al., “Spatial–temporal data-driven full driving cycle prediction for optimal energy management of battery/supercapacitor electric vehicles,” Energy Convers. Manage., vol. 277, 2023, Art. no. 116619, doi: 10.1016/j.enconman.2022.116619.   [5] M. Li, Y. Wang, P. Yu, Z. Sun, and Z. Chen, “Online adaptive energy management strategy for fuel cell hybrid vehicles based on improved cluster and regression learner,” Energy Convers. Manage., vol. 292, 2023, Art. no. 117388, doi: 10.1016/j.enconman.2023.117388.   [6] M. Li, L. Wang, Y. Wang, and Z. Chen, “Sizing optimization and energy management strategy for hybrid energy storage system using multi objective optimization and random forests,” IEEE Trans. Power Electron., vol. 36, no. 10, pp. 11421–11430, Oct. 2021, doi: 10.1109/ TPEL.2021.3070393.   [7] Q. Yu, Y. Liu, S. Long, X. Jin, J. Li, and W. Shen, “A branch current estimation and correction method for a parallel connected battery system based on dual BP neural networks,” Green Energy Intell. Transp., vol. 1, no. 2, 2022, Art. no. 100029, doi: 10.1016/j.geits.2022.100029.   [8] B. Hredzak, V. G. Agelidis, and M. Jang, “A model predictive control system for a hybrid battery-ultracapacitor power source,” IEEE Trans. Power Electron., vol. 29, no. 3, pp. 1469–1479, Mar. 2014.   [9] N.-D. Nguyen, C. Yoon, and Y. I. Lee, “A standalone energy management system of battery/supercapacitor hybrid energy storage system for electric vehicles using model predictive control,” IEEE Trans. Ind. Electron.,vol. 70, no. 5, pp. 5104–5114, May 2023.   [10] S. A. G. K. Abadi, S. I. Habibi, T.Khalili, and A. Bidram, “A model predictive control strategy for performance improvement of hybrid energy storage systems in DC microgrids,” IEEE Access, vol. 10, pp. 25400–25421, 2022.
