BOARD CHARGER (OBC) FOR ELECTRIC VEHICLES

This paper presented a complete modeling, control design, and simulation study of a 3.3 kW dual-stage On-Board Charger (OBC) for electric vehicles. The proposed PI-controlled PFC boost converter and isolated DC-DC converter configuration achieves high efficiency (95.4%), excellent power quality (PF 0.994, THD 2.85%), and smooth CC-CV battery charging transition. The continuous closed-loop feedback guarantees fast dynamic suppression of grid disturbance and voltage overshoot. Future research will explore adaptive fuzzy-PI hybrid tuning and SiC semiconductor physical prototype validation.

[1] M. Yilmaz and P. T. Krein, "Review of battery charger topologies, charging power levels, and infrastructure for plug-in electric vehicles," IEEE Trans. Power Electron., vol. 28, no. 5, pp. 2151–2169, May 2013. [2] B. Singh et al., "A review of single-phase improved power quality AC-DC converters," IEEE Trans. Ind. Electron., vol. 50, no. 5, pp. 962–981, Oct. 2003. [3] S. H. Lee et al., "Design and control of a high-efficiency on-board charger for electric vehicles," IEEE Trans. Veh. Technol., vol. 63, no. 1, pp. 104–114, Jan. 2014. [4]  K. J. Åström and T. Hägglund, Advanced PID Control. Research Triangle Park, NC: ISA, 2006. [5]  H. Li et al., "Dual-active-bridge converter for EV charging applications," IEEE Trans. Power Electron., vol. 34, no. 3, pp. 2180–2192, Mar. 2019. [6]  J. P. Oliver, "Digital control of power factor correction circuits in EV chargers," IEEE Ind. Appl. Mag., vol. 22, no. 4, pp. 45–54, Jul. 2016. [7] R. Erickson and D. Maksimovic, Fundamentals of Power Electronics, 3rd ed. Springer, 2020. [8]  A. Sharma and V. Jogdand, "Comparative analysis of power electronic converters for automotive battery chargers," Int. J. Electr. Eng. Res., vol. 12, no. 2, pp. 88–97, 2022. [9] IEEE Standard 519-2014, IEEE Recommended Practice and Requirements for Harmonic Control in Electric Power Systems, IEEE, 2014. [10]IEC 61000-3-2:2018, Electromagnetic Compatibility (EMC) - Limits for Harmonic Current Emissions, International Electrotechnical Commission, 2018.
