DEVELOPMENT OF A LINUX REAL-TIME LATENCY MONITORING, STORAGE AND VISUALIZATION SYSTEM

This paper presented the development of a Linux-based real-time latency monitoring, storage, and visualization system using RTLA timerlat. The proposed architecture integrates RTLA-based latency measurement with a Python data collector, SQLite database, Flask backend, and web-based dashboard. This provides a continuous data path from operating-system-level latency measurement to persistent storage and graphical visualization. The experimental results demonstrate the practical operation of the developed system. The documented cyclictest experiment produced a minimum latency of 26 µs, an average latency of 973 µs, and a maximum latency of 16 ms. The project also demonstrated the use of the RTLA timerlat top and timerlat hist interfaces and the subsequent processing of latency information through collector.py, SQLite, app.py, and the dashboard. The normal- and high-latency experiments further demonstrated the ability of the system to classify and visualize different latency conditions through the web dashboard. The documented results show the complete processing sequence involving the collector, database, Python application, and dashboard for both conditions. The developed system therefore provides a practical foundation for continuous Linux latency observation without depending solely on manual inspection of command-line output. The current implementation focuses on measurement, collection, storage, threshold-based classification, and visualization, while machine-learning prediction, hardware performance-counter integration, virtualization analysis, and automated notification remain potential areas for future development.

[1]  The Linux Kernel Documentation, “rtla—Real-time Linux Analysis tool,” Linux Kernel Documentation, accessed Sep. 2026. [2]  The Linux Kernel Documentation, “rtla-timerlat—Measures the operating system timer latency,” Linux Kernel Documentation, accessed Sep. 2026. [3]  Python Software Foundation, “sqlite3—DB-API 2.0 interface for SQLite databases,” Python Documentation, accessed Sep. 2026. [4]  Pallets Projects, “Quickstart—Flask Documentation,” Flask Documentation, accessed Sep. 2026. [5]  Linux Foundation, “Cyclictest,” Real-Time Linux Documentation, accessed Sep. 2026. [6]  The Linux Kernel Documentation, “Scheduler,” Linux Kernel Documentation, accessed Sep. 2026. [7]  The Linux Kernel Documentation, “Real-time preemption,” Linux Kernel Documentation, accessed Sep. 2026. [8]  S. Rostedt, “ftrace—Function Tracer,” The Linux Kernel Documentation, Linux Kernel Documentation, accessed Sep. 2026. [9]  The Linux Kernel Documentation, “Performance Counters for Linux,” Linux Kernel Source Documentation, accessed Sep. 2026. [10]    J. M. Domingos, P. Tomas, and L. Sousa, “Supporting RISC-V performance counters through performance analysis tools for Linux (Perf),” arXiv preprint arXiv:2112.11767, 2021.
