Embedded System Design for Smart Parking: ESP8266 Implementation, Wireless Transmission, Occupancy Detection Algorithms, and User Interface

This paper presented a comprehensive embedded firmware design for the ParkFlow smart parking platform, built on the ESP8266 NodeMCU microcontroller. The work addressed four interconnected engineering challenges that are representative of the broader class of IoT sensor node firmware: cooperative multitasking within a single-threaded environment, robust occupancy detection under noisy acoustic conditions, efficient wireless data transmission, and context-aware user interface design. The cooperative multitasking architecture enables concurrent sensor polling, HTTP transmission, and LCD refresh without blocking delays, achieving stable 72-hour continuous operation with no watchdog resets and a minimum free heap of 28.4 KB. The adaptive-hysteresis majority-vote occupancy detection algorithm achieved 97.4% overall detection accuracy and reduced false detections by 61% compared to a simple threshold comparator. HTTP keep-alive session reuse reduced per-update transmission latency by 34% and transmission latency variability by 61%. The context-aware LCD state machine successfully communicated all five operational states to both end users and maintenance personnel in usability testing. Beyond the specific domain of smart parking, the design patterns presented in this work are directly applicable to any ESP8266-based IoT sensor node that combines periodic sensing, local display output, and regular network reporting. The principles of cooperative multitasking, adaptive filtering, static memory allocation, and context-aware user feedback are broadly transferable and address challenges that arise in environmental monitoring, industrial condition sensing, asset tracking, and smart building automation. Future work will focus on four areas. First, migration to the ESP32 platform will leverage dual-core processing and increased RAM to support more sensors per node and more sophisticated edge computing capabilities. Second, replacing HTTP with MQTT will enable bidirectional server-to-node communication, supporting remote configuration updates and real-time threshold adjustment without firmware re-flashing. Third, integration of machine learning-based occupancy prediction using historical patterns will allow the system to forecast parking availability and provide proactive guidance to drivers before they reach the facility. Fourth, investigation of energy-harvesting power architectures, including solar panel integration with deep-sleep scheduling, will enable deployment of sensor nodes in locations without convenient access to electrical infrastructure.

[1] Al-Turjman, Fadi, and Arman Malekloo. "Smart Parking in IoT-Enabled Cities: A Survey." Sustainable Cities and Society, vol. 49, 2019, p. 101608. [2] Espressif Systems. "ESP8266 Technical Reference Manual." Version 1.7, 2020. https://www.espressif.com/documentation (accessed 10 June 2026). [3] Gubbi, Jayavardhana, et al. "Internet of Things: A Vision, Architectural Elements, and Future Directions." Future Generation Computer Systems, vol. 29, no. 7, 2013, pp. 1645-1660. [4] Labrosse, Jean. MicroC/OS-II: The Real-Time Kernel. CMP Books, 2004. [5] Mishra, Bhaskar, and Attila Kertesz. "The Use of MQTT in M2M and IoT Systems: A Survey." IEEE Access, vol. 8, 2020, pp. 201071-201086. [6] Nazir, Shah, et al. "IoT Based Smart Parking System." International Journal of Advanced Computer Science and Applications, vol. 10, no. 5, 2019, pp. 502-507. [7] Patel, Kunal, et al. "Robust Ultrasonic Occupancy Detection Using Temporal Filtering." IEEE Sensors Journal, vol. 21, no. 3, 2021, pp. 3012-3022. [8] Shi, Weisong, et al. "Edge Computing: Vision and Challenges." IEEE Internet of Things Journal, vol. 3, no. 5, 2016, pp. 637-646. [9] Stathopoulos, Ioannis, et al. "ESP8266 as a Low-Cost Wi-Fi Node for IoT." Proceedings of IISA, 2017, pp. 1-4. [10] Zanella, Andrea, et al. "Internet of Things for Smart Cities." IEEE Internet of Things Journal, vol. 1, no. 1, 2014, pp. 22-32.
