FPGA Performance Characterization of an 8-Bit Ordinary Truncated Multiplier under Progressive Timing Constraints

This work presents an 8-bit ordinary truncated multiplier has been characterized on a Zynq-7000 XC7Z020 FPGA over 17 post-route timing targets from 50 to 225 MHz. With CUT=6, 21 of the 64 elementary partial products are eliminated and no correction term is introduced. All measured runs maintain positive setup WNS; at the 225-MHz target the routed design reports +0.413 ns WNS, 4.031 ns critical delay, a slack-derived frequency estimate of 248.08 MHz, 72 LUTs, 34 FFs, 23 mW dynamic power, 0.0927 nJ PDP, and 290.23 LUT·ns ADP. Relative to the 50-MHz implementation, timing-driven optimization reduces critical delay by approximately 43.5% while LUT count increases by 33.3%. ADP nevertheless improves by approximately 24.6%. Exhaustive arithmetic evaluation shows all possible input combinations MED=80.25, WCE=321, error rate=93.75%, and mean signed error=-80.25, verifying the expected one-sided bias of uncompensated truncation. This study consequently establishes a controlled FPGA and numerical reference point for the next phase, in which fixed-bias and boundary-weighted compensation methods can be compared according to the additional hardware needed to recover accuracy.

[1] N. Petra, D. De Caro, V. Garofalo, E. Napoli, and A. G. M. Strollo, “Truncated Binary Multipliers With Variable Correction and Minimum Mean Square Error,” IEEE Trans. Circuits Syst. I, Reg. Papers, vol. 57, no. 6, pp. 1312–1325, 2010, doi: 10.1109/TCSI.2009.2033536.   [2] V. Garofalo, N. Petra, and E. Napoli, “Analytical Calculation of the Maximum Error for a Family of Truncated Multipliers Providing Minimum Mean Square Error,” IEEE Trans. Comput., vol. 60, no. 9, pp. 1366–1371, 2011, doi: 10.1109/TC.2010.236. [3] G. Zervakis, K. Tsoumanis, S. Xydis, D. Soudris, and K. Pekmestzi, “Design-Efficient Approximate Multiplication Circuits Through Partial Product Perforation,” IEEE Trans. Very Large Scale Integr. (VLSI) Syst., vol. 24, no. 10, pp. 3105–3117, Oct. 2016, doi: 10.1109/TVLSI.2016.2535398.   [4] S. Vahdat, M. Kamal, A. Afzali-Kusha, and M. Pedram, “TOSAM: An Energy-Efficient Truncation- and Rounding-Based Scalable Approximate Multiplier,” IEEE Trans. Very Large Scale Integr. (VLSI) Syst., vol. 27, no. 5, pp. 1161–1173, May 2019, doi: 10.1109/TVLSI.2018.2890712.   [5] P. Kulkarni, P. Gupta, and M. Ercegovac, “Trading Accuracy for Power With an Underdesigned Multiplier Architecture,” in Proc. 24th Int. Conf. VLSI Design, 2011, pp. 346–351, doi: 10.1109/VLSID.2011.51.   [6] R. Zendegani, M. Kamal, M. Bahadori, A. Afzali-Kusha, and M. Pedram, “RoBA Multiplier: A Rounding-Based Approximate Multiplier for High-Speed Yet Energy-Efficient Digital Signal Processing,” IEEE Trans. Very Large Scale Integr. (VLSI) Syst., vol. 25, no. 2, pp. 393–401, Feb. 2017, doi: 10.1109/TVLSI.2016.2587696.
