Gain-Scheduled PI Control of a PV-Fed DC–DC Boost Converter for Ripple-Reduced Battery Charging Under Dynamic Load Conditions

This paper presented the design and MATLAB-based simulation of an adaptive ripple-smoothing controlled DC–DC converter for solar PV battery charging using dynamic load profiling and a gain-scheduled adaptive PI controller. The complete framework — PV source, boost converter, LC filter, adaptive controller, dynamic load, and CC–CV battery model with SOC, internal resistance and polarization dynamics — was implemented and validated end-to-end. Using values taken directly from the simulation log, the system regulates the charging voltage to within 0.48% of the 54.6 V reference, reduces steady-state ripple voltage by 84.32%, and reproduces realistic CC-to-CV battery charging behavior with SOC progressing from 40% to 67.28% over five hours. Future work will focus on extending the proposed controller by developing a continuous adaptive gain scheduling mechanism, improving ripple modelling based on switching-frequency dynamics, validating the proposed approach using hardware-in-the-loop or experimental prototype implementation, and evaluating controller performance under real-time stochastic load profiles and varying environmental conditions.

A. Kumar and M. Singh, "Adaptive ripple-power compensation in single-phase AC–DC converters for PV battery charging," IEEE Transactions on Power Electronics, vol. 35, no. 12, pp. 12489–12501, 2020. [2] L. Zhao et al., "Model predictive control for ripple minimization in single-phase rectifiers," IEEE Transactions on Industrial Electronics, vol. 69, no. 2, pp. 1355–1366, 2022. [3] T. Nguyen and J. Park, "Solar PV charger with adaptive smoothing control for variable irradiance," Solar Energy, vol. 231, pp. 456–467, 2022. [4] J. Khan et al., "Design of a high-efficiency PV battery charger with dynamic load adaptation," Energy Conversion and Management, vol. 252, p. 115123, 2022. [5] G. Li and P. Wang, "Improved charging stability in PV–battery systems using real-time load pattern prediction," Applied Energy, vol. 310, p. 118573, 2022. [6] D. B. Patel and A. Shah, "Performance enhancement of PV chargers using load-profile-based adaptive rectifier control," IJRER, vol. 12, no. 4, pp. 1802–1810, 2022. [7] T. K. Singh and A. Raj, "Optimization of battery charging circuits in PV-based charging using adaptive predictive control," IEEE Transactions on Industrial Applications, vol. 60, no. 1, pp. 905–916, 2024.
