Improving Power Quality and Managing Power in a PV-HESS Based Grid-Tied Microgrid with a Model Predictive Control Method

For the stable operation under imbalanced loading conditions and harmonic mitigation due to nonlinear loads, a control strategy based on the Modified Leaky Least Mean Square algorithm was effectively implemented in the carried-out analysis of the investigated system. A power-sharing framework is also put in place to ensure that active power is distributed effectively. The suggested controller has strong and consistent performance over a range of challenging operating situations, in MATLAB/Simulink simulations. The total harmonic distortion (THD) in the source current was drastically reduced by the MLLMS-based algorithm, leading to an improvement in power quality. In addition, the converter is efficiently controlled by the Finite Control Set Model Predictive Control, which accurately tracks the reference values and generates optimal switching states. The suggested control architecture guarantees high-quality power at the source, maintains stable DC-bus voltages, and offers balanced active power sharing capabilities. These findings suggest that grid-connected microgrids with hybrid energy storage systems benefit from the system's ability to enhance power management and quality.

[1] A. Jain, P.Das, S.Yamujala, R. Bhakar, and J. Mathur, “Resource potential and variability assessment of solar and wind energy in India,” Energy, vol. 211, 2020, Art. no.  118993.   [2] K. S. Tey and S. Mekhilef, “Modified incremental conductance algorithm for photovoltaic system under partial shading conditions and load variation,” IEEE Trans. Ind. Electron., vol. 61, no. 10, pp. 5384–5392, Oct. 2014.   [3] H. Renaudineau et al., “A PSO-based global MPPT technique for distributed PV power generation,” IEEE Trans. Ind. Electron., vol. 62, no. 2, pp. 1047–1058, Feb. 2015.   [4] S. Padmanaban, N. Priyadarshi, M. S. Bhaskar, J. B. Holm-Nielsen, E. Hossain, and F. Azam, “A hybrid photovoltaic-fuel cell for grid integration with Jaya-based maximum power point tracking: Experimental performance evaluation,” IEEE Access, vol. 7, pp. 82978–82990, 2019.   [5] D. Sera, L. Mathe, T. Kerekes, S. V. Spataru, and R. Teodorescu, “On the perturb-and-observe and incremental conductance MPPT methods for PV systems,” IEEE J. Photovolt., vol. 3, no. 3, pp. 1070–1078, Jul. 2013.     [6] A. Khaligh and Z. Li, “Battery, ultracapacitor, fuel cell, and hybrid energy storage systems for electric, hybrid electric, fuel cell, and plug-in hybrid electric vehicles: State of the art,” IEEE Trans. Veh. Technol., vol. 59, no. 6, pp. 2806–2814, Jul. 2010.   [7] C. J. Jena and P. K. Ray, “Power management in three-phase gridintegrated PV system with hybrid energy storage system,” Energies, vol. 16, no. 4, 2023, Art. no. 2030.   [8] P. Singh and J. S. Lather, “Power management and control of a gridindependent DC microgrid with hybrid energy storage system,” Sustain. Energy Technol. Assessments, vol. 43, 2021, Art. no. 100924.   [9] M. Panda, V. B. Devara, and T. Maity, “A novel DC bus-signaling based power management strategy for DC microgrid,” Int. Trans. Elect. Energy Syst., vol. 31, no. 2, 2021, Art. no. e12758.   [10] N. Mahmud, A. Zahedi, and A. Mahmud, “A cooperative operation of novel PV inverter control scheme and storage energy management system based on ANFIS for voltage regulation of grid-tied PC system,” IEEE Trans. Ind. Inform., vol. 13, no. 5, pp. 2657–2668, Oct. 2017.
