Reducing Non-Revenue of Water Using Non-Return Valves in Ground Based Water Retaining Reservoir and Its Bottom Treatment : A Field Study from Jal Jeevan Mission, Maharashtra, India

This paper has documented the groundwater-induced structural failure of the bottom treatment system of a 37 ML RCC balancing tank under the Jal Jeevan Mission at Sarade Village, Satara District, Maharashtra, and demonstrated the successful remediation using a perforated PVC pipe grid network integrated with Non-Return Valves. The following conclusions are drawn: 1. Seepage from adjacent unlined irrigation canals can raise groundwater tables to levels capable of generating structural uplift failures in empty or partially-filled balancing tanks. 2. The composite bottom treatment (soil + geomembrane + sand boxing + Shahabad tile) is vulnerable to delamination under net uplift conditions; the geomembrane is particularly susceptible to ballooning and puncture. 3. The NRV-integrated perforated PVC underdrain system provides passive, automatic pressure relief that prevents sub-slab pressure build-up without requiring active pumping during normal operation. 4. Post-remediation field monitoring confirmed zero recurrence of buoyancy-induced structural distress, validating the NRV system's effectiveness. 5. Compared to conventional countermeasures (ground anchors, slab thickening, dewatering wells), the NRV underdrain system offers superior cost-effectiveness, passive operation, and retrofit suitability. 6. Adoption of this system as a standard design element in JJM and CPHEEO guidelines for canal-adjacent balancing tanks is strongly recommended.

[1] Ministry of Jal Shakti. (2019). Jal Jeevan Mission: Operational Guidelines. Government of India, New Delhi. [2] Jain, A., & Goel, R. (2017). Failure Analysis of Underground Water Tanks: A Review of Municipal Balancing Tank Failures in India. Journal of Structural Engineering (India), 44(2), 112–121. [3] ACI Committee 350. (2012). Commentary on Code Requirements for Environmental Engineering Concrete Structures (ACI 350R-12). American Concrete Institute, Farmington Hills, MI. [4] Bureau of Indian Standards. (2009). IS 3370 (Part 2): Code of Practice for Concrete Structures for the Storage of Liquids – Part 2: Reinforced Concrete Structures. BIS, New Delhi. [5] Central Public Health and Environmental Engineering Organisation (CPHEEO). (1999). Manual on Water Supply and Treatment (3rd ed.). Ministry of Urban Development, Government of India. [6] Bowles, J. E. (1996). Foundation Analysis and Design (5th ed.). McGraw-Hill, New York. [7] Brinkgreve, R. B. J., & Broere, W. (2008). PLAXIS 2D Reference Manual. Plaxis BV, Delft, Netherlands. [8] Sharma, R., & Singh, A. (2020). Sustainability Assessment of Rural Water Supply Projects in India. Journal of Environmental Management, 264, 110456. https://doi.org/10.1016/j.jenvman.2020.110456 [9] Kumar, V., Patil, M., & Rao, S. (2021). GIS-Based Environmental Impact Assessment for Rural Infrastructure Development. Environmental Impact Assessment Review, 89, 106591. https://doi.org/10.1016/j.eiar.2021.106591 [10] Gaikwad, R. S., & Gawande, S. (2023). Preventing Structural Failure of Balancing Tank Raft and Bottom Treatment Due to Groundwater Table Rise Using Non-Returning Valves. Unpublished Technical Report, JJM Maharashtra.
