ArticlePeer ReviewedOpen AccessPlagiarism Passed
Paper ID:IJSREM65685

DESIGN AND COMPARATIVE ANALYSIS of A MODIFIED PERFORMANCE OPTIMIZED BBL-PT FULL ADDER IN 90nm CMOS TECHNOLOGY

Stream/Area:

-

Subject:

-

Paper ID:

IJSREM65685

Volume:

10 |

6 |

Jun 2026

Pages:

1-8

Publication Frequency:

Monthly (12 issues per year)

DOI
Digital Object Identifier
10.55041/IJSREM65685

License:International Journal of Scientific Research in Engineering and Management follows the Creative Commons Attribution 4.0 (CC BY 4.0) License, allowing free use and distribution with proper attribution.

Share this article:

Authors

B.NAGASARASWATHI

B.NAGASARASWATHI

ECE

JNTUGV-CEV

Download Author Certificate

Mentors

G.APPALA NAIDU

G.APPALA NAIDU

ECE

JNTUGV-CEV

Download Mentor Certificate

Author Services & Downloads

Full ArticlesAcceptance Certificate

Abstract

Full adder is one of the basic circuits in arithmetic operations and its performance affects the speed and power dissipation of VLSI systems. Though the existing BBL-PT full adder has low power dissipation and less transistor count; however, there exists voltage stepping in PTL-based sum block due to PMOS restorer circuit which degrades the output signals quality and increases delay. Though the hybrid LP XOR/XNOR full adder eliminates this problem; it increases transistor count. To overcome these problems, three modified BBL-PT full adder designs are proposed. Proposed designs aim for elimination of voltage stepping, reduction in transistor count, reduction in power dissipation, and improvement in Power-Delay Product (PDP). All proposed circuits have been designed and simulated using Cadence Virtuoso at 90nm CMOS technology having supply voltage of 1.2V. Simulation results show improvement in power dissipation, delay, and PDP as compared to the existing full adder designs.

KEYWORDS

Full Adder BBL-PT Hybrid Logic XOR/XNOR CMOS PDP Cadence Virtuoso

Cite This Article

B.NAGASARASWATHI, G.APPALA NAIDU, "DESIGN AND COMPARATIVE ANALYSIS of A MODIFIED PERFORMANCE OPTIMIZED BBL-PT FULL ADDER IN 90nm CMOS TECHNOLOGY," International Journal of Scientific Research in Engineering and Management, vol. 10, no. 6, pp. 1-8, Jun 2026. https://doi.org/10.55041/IJSREM65685

Full Article/Conclusion

This work presented the design and comparative analysis of three modified BBL-PT based full adder architectures implemented using 90 nm CMOS technology. The study began by analyzing existing full adder designs, including Conventional CMOS, Complementary Pass Logic (CPL), the BBL-PT full adder, and the Hybrid LP XOR/XNOR full adder. Although these architectures offer improvements in specific performance metrics, the conventional BBL-PT full adder suffers from a voltage stepping problem in the PTL-based sum block due to the PMOS restorer, while the Hybrid LP XOR/XNOR design increases transistor count and circuit complexity. These limitations motivated the development of modified BBL-PT architectures capable of achieving a better balance between power consumption, propagation delay, transistor count, and signal integrity. To address these challenges, three modified full adder architectures were proposed with different optimization objectives. The first design improves voltage stability by incorporating a current-source-assisted sum block, the second design employs optimized hybrid logic with separate sum and carry paths to reduce the critical path delay, and the third design utilizes a compact hybrid pass transistor structure to minimize transistor count and switching capacitance. Simulation results obtained using Cadence Virtuoso demonstrate that all three proposed designs successfully eliminate the voltage stepping issue and improve the overall performance of the full adder. Among them, Proposed Design–2 achieves the best overall Power-Delay Product (PDP) and propagation delay, whereas Proposed Design–3 offers the lowest transistor count and power consumption. These results indicate that the proposed architectures are promising candidates for energy-efficient and high-speed arithmetic circuits in modern VLSI systems.

References

1)      R. Zimmermann and W. Fichtner, “Low-power logic styles: CMOS versus pass-transistor logic,” IEEE Journal of Solid-State Circuits, vol. 32, no. 7, pp. 1079–1090, Jul. 1997. 2)      C. H. Chang, J. Gu, and M. Zhang, “A review of 0.18-μm full adder performances for tree-structured arithmetic circuits,” IEEE Transactions on Very Large Scale Integration (VLSI) Systems, vol. 13, no. 6, pp. 686–695, Jun. 2005. 3)      S. Goel, A. Kumar, and M. A. Bayoumi, “Design of robust, energy-efficient full adders for deep-submicrometer design using hybrid-CMOS logic style,” IEEE Transactions on VLSI Systems, vol. 14, no. 12, pp. 1309–1321, Dec. 2006. 4)      J. Kandpal, A. Tomar, M. Agarwal and K. K. Sharma, "High-Speed Hybrid-Logic Full Adder Using High-Performance 10-T XOR–XNOR Cell," IEEE Transactions on Very Large Scale Integration (VLSI) Systems, vol. 28, no. 6, pp. 1413-1422, 2020. 5)      Dr. N. Suresh, Dr. Dhanalakshmi Gopal, Dr.A.Rosi, Dr.P.Sivakumar, Dr.D.Ferlin Deva        Shahila, Dr.Ashwini.A, “Hybrid Logic Style CMOS Full Adder Using 10-T XOR & XNOR Circuit” 2024 7th International Conference on Circuit Power and Computing Technologies ©2024 IEEE | DOI: 10.1109/ICCPCT61902.2024.10672927. 6)      Pallavi Chauhan, Abhishek Tomar, Neha Singh, “Design and Analysis of a 1-Bit Full Adder Utilizing a Novel Grounded Keeper XOR-XNOR Circuit” 2025 3rd International Conference on Device Intelligence, Computing and Communication Technologies (DICCT) 2025 IEEE | DOI: 10.1109/DICCT64131.2025.10986359. 7)      Hassoune, D. Flandre, I. O’Connor, and J.-D. Legat, “ULPFA: A new efficient design of a power-aware full adder,” IEEE Transactions on Circuits and Systems II: Express Briefs, vol. 57, no. 3, pp. 206–210, Mar. 2010. 8)      M. Akshath, K. Kumar, and P. K. Shetty, “Design and analysis of low-power 10 transistor full adders using novel XOR–XNOR gates,” in Proc. 2nd Int. Conf. Computing, Semiconductor, Mechatronics, Intelligent Systems and Communications (COSMIC), 2025, doi: 10.1109/COSMIC67569.2025.11380860. 9)      S. Ishraq, S. R. Ahamed, I. Hussain, and P. Ghosh, “A new 16T full adder design for full-swing outputs,” in Proc. IEEE 21st India Council Int. Conf. (INDICON), 2024, doi: 10.1109/INDICON63790.2024.10958477. 10)   R. Jain, P. Singh, A. Sharma, and R. Sharma, “Design, simulation and analysis of energy efficient 1-bit full adder at 90nm CMOS technology for deep submicron levels,” in Proc. Int. Conf. Computing, Communication and Automation (ICCCA), 2016.
