The present study introduces a space-optimized, aperture-engineered microstrip patch an- tenna synthesized for dual-band operation across 4G LTE and sub-6 GHz 5G wireless communication standards. The presented geometry is physically realized on an FR4 laminate (relative permittivity εᵣ = 4.4, vertical thickness h = 1.6 mm) and numerically characterized using CST Studio Suite. Mirror-image aperture etching on the radiating patch induces controlled perturbation of surface current den- sity, <u>thereby</u> generating two distinct resonant modes at approximately 2.7 GHz and 4.5 GHz. The antenna attains reflection coefficient (S₁₁) inferior to –20 dB at the lower spectral window and –60 dB at the upper band, with voltage standing wave ratio (VSWR) ≤ 1.05 at 4.5 GHz. Experimentally obtained data confirm consistent far-field emission patterns, side lobe levels inferior to –2.4 dB, and uniform directivity across both frequency bands. The dimensionally economical footprint (40 × 30 mm) and manufacturing tolerance resilience <u>collectively</u> render the presented antenna a practically viable, economically favourable solution for contemporary 4G/5G terminals.
KEYWORDS
A dual-resonance microstrip patch radiator has been successfully synthesized, numerically analysed, physically fabricated, and experimentally corrobo- rated for 4G LTE and sub-6 GHz 5G wireless com- munication applications. The presented radiator at- tains frequency alignment at approximately 2.6 GHz (simulated) / 2.7 GHz (measured) and 4.45 GHz (simulated) / 4.5–5 GHz (measured), encom- passing the target spectral windows. Simulated and experimentally obtained data demon- strate favourable input impedance alignment with reflection coefficient inferior to –10 dB and VSWR inferior to 2 at both operating frequencies. The far- field spatial distributions exhibit consistent and quasi-omnidirectional characteristics with side lobe levels inferior to –2.4 dB, ensuring dependable sig- nal coverage. The radiator provides satisfactory re- alized gain (2-5 dB) and uniform directivity, render- ing it appropriate for practical deployment. The dual-resonance behaviour is realized through mirror-image aperture incorporation in the radiating patch, which generates multiple resonant pathways without increasing physical dimensions. The radia- tor offers a dimensionally economical (40 × 30 mm), economically favourable (FR4-based), manu- facturing-tolerant solution for contemporary 4G and 5G communication systems. Subsequent investigations may explore spectral width expansion using vertically stacked parasitic radiators, gain elevation through dielectric super- strate loading, and incorporation into multiple-input multiple-output (MIMO) architectures for enhanced data throughput.
[1] K. Ruchandani and M. Kumar, "A novel CPW fed octagonal aperture UWB antenna with 5GHz/6GHz band rejection by H-shaped slot," in *IEEE International Conference on Computer, Communication and Control (IC4-2015)*, Kota, Rajasthan, India, pp. 1–5, 2015. [2] H. Mardani, C. Ghobadi, and J. Nourinia, "A simple compact monopole antenna with variable single- and double-filtering function for UWB ap- plications," IEEE Antennas and Wireless Propaga- tion Letters, vol. 10, pp. 127–129, 2011. [3] R. Azim and A. M. H. Meaze, "A multi-slotted antenna for LTE/5G sub-6 GHz wireless communi- cation applications," International Journal oMicro- wave and Wireless Technologies, 2020. [4] S. K. Ezzulddin, S. O. Hasan, and M. M. Ameen, "Microstrip patch antenna design, simulation and fabrication for 5G applications," 2012. [5] T. Tewary and S. Bhunia, "Compact broadband microstrip patch antenna for 5G communication ap- plications," received 20 April 2025; revised 20 Au- gust 2025; published 29 August 2025. [6] O. D. Hussein and A. A. Hussein, "Design of microstrip patch antenna for radar and 5G applica- tions," ESP Journal of Engineering & Technology Advancements, 2023.
