EFFECT OF TEMPERATURE ON THE MECHANICAL PROPERTIES OF COMPOSITE MATERIALS EXPOSED TO AVIATION FLUIDS

The study investigated the influence of aviation-fuel exposure and temperature on the thermal and mechanical behaviour of a glass-fibre-reinforced plastic composite. GFRP laminates were fabricated by hand lay-up and exposed to ATF and OX38 for seven days at 50 °C and 80 °C, after which thermal, impact, tensile and flexural properties were evaluated.   ·      The Glass Transition (Tg) thermal showed temperature-dependent changes in the composite material, indicating changes in its thermal behaviour as the temperature increased. ·      ATF showed greater absorption or interaction with the GFRP specimens than OX38 in the project observations. ·      Exposure to both ATF and OX38 affected the impact, tensile and flexural behaviour of the composite. ·      Impact strength decreased after exposure to both aviation fuels; the average recorded impact energy was 70.8 J for the original condition and 57.7, 55.3, 58.2 and 56.4 J for the four exposed conditions. ·      ATF produced a greater overall change in mechanical properties than OX38 according to the project interpretation. ·      Increasing the exposure temperature from 50 °C to 80 °C influenced the mechanical behaviour of the composite. ·      The thermal and mechanical results indicate that aviation-fuel exposure and elevated temperature should be considered when evaluating GFRP materials for aerospace applications.

[1] Chi-Hungshen et al., “Effect of Moisture and Temperature on the Tensile Strength of Composite Material,” Journal of Composite Materials, vol. 11, 1977, pp. 12–16. [2] A. M. Amaro et al., “Effect of Commercial Oils on Mechanical Properties of Composite Materials,” Composite Structures, vol. 118, 2014, pp. 1–8. [3] V. P. Nikolaev et al., “Effect of Temperature on the Mechanical Properties of Composite Materials,” Zavodskaya Laboratoriya. Diagnostika Materialov, vol. 79, no. 4, 2013, pp. 58–61. [4] N. Mortas et al., “Effect of Corrosive Solutions on Composite Laminates Subjected to Low Velocity Impact Loading,” Composite Structures, vol. 108, 2014, pp. 205–211. [5] A. M. Amaro et al., “Effect of Alkaline and Acidic Solutions on Glass/Epoxy Composites,” Polymer Degradation and Stability, vol. 98, 2013, pp. 853–862. [6] M. H. Banna et al., “Effects of Two Aqueous Acidic Solutions on Polyester and Bisphenol-A Epoxy Vinyl Ester Resins,” Materials Science and Engineering A, vol. 528, 2011, pp. 2137–2142. [7] M. Stamenovic et al., “Effect of Alkaline and Acidic Solutions on the Tensile Properties of Glass–Polyester Pipes,” Materials & Design, 2011. [8] A. M. Amaro et al., “Influence of Multi Impacts on GFRP Composite Laminates,” Composites Part B, vol. 52, 2013, pp. 93–99. [9] Y. S. Wang et al., “Effect of Temperature on Mechanical Properties Ti-Based Metallic Glass Matrix Composite,” Intermetallics, vol. 67, 2015, pp. 121–126.
